Day Night rotation

Watchface Design Expression Help
1

I have a face that has the opening on the side for day and night but having problems with rotation.

Gemini_Generated_Image_h26cj7h26cj7h26c
Gemini_Generated_Image_h26cj7h26cj7h26c1024×1024 69.4 KB

This is the image I am trying to get to rotate

3 Likes
2

check this tutorial and the improvements I have made:

4 Likes
3

Beautiful image

3 Likes
4

For a sun[rise/set] progression rather than flip I made a test face a while back:

4 Likes
5

Thank you for sharing that Rob . Looking forward to seeing the Formulas .

2 Likes
6

You should remember it. This ring a bell on one of your faces? This was my work-through face helping with the expressions on that.

<-SR
 -
 -
 -
>-
 -
 -
 -
<-SS
2 Likes
7

Yes . I remember it well . I posted a link to the Face on a Similar topic . Your test makes it easier to find the Formulas . Thanks again . :+1::blush:

2 Likes
8

Thank you

1 Like
9

Thank you for that I was reading that one before and the info was great but was having problems with the face i have its not on the top but on the side was having problems with the numbers. Pulled all my hair out :slight_smile: I made it just switch from day to night instead of the rotation. Someday I will figure that part out.https://beta.facer.io/watchface/HFZrK36le8

3 Likes
10

I’ll see if I can add a rotary circle to the demo face. The expressions may well boggle me at first. It’s been a while. I wonder if it was before I started keeping regular files of all the complex ones with annotations.

Fantastic face though.

2 Likes
11

So you used two same images differently rotated and switched them with opacity like $#DISDAYTIME#=1?100:0$
You could do the same with just one image with 100 opacity, and rotation like $#DISDAYTIME#=1?0:180$
Question is, how do you imagine the rotation? That the image will continuously turn over 24h, or that it does some slow turning in the minutes (how many) around sunset/sunrise, or it just flips like I described earlier?

3 Likes
12

Wow, the screen is beautiful, and the highlight of the Sun and Moon :clap::clap::clap:

2 Likes
13

Thank you for the compliment

1 Like
14

was thinking it would be a slow rotation based on time so the sun and moon will show at the same time at some point

2 Likes
15

Ok,
a) set the image opacity to 100 (no formula there)
b) set the rotation like this
(180+9*(clamp((((#WSUNRISEH#*60)+#WSUNRISEM#)-(#DH#*60+#Dm#+#Ds#/60)+10),0,20)+clamp((((#WSUNSETH24#*60)+#WSUNSETM#)-(#DH#*60+#Dm#+#Ds#/60)+10),0,20)))
it will start 10 min before and finishes 10 min after the sun goes up or down
c) cosmetics: I would change the cutout shape, or shift the rotating image more to right, to avoid the corners showing the opposite side

6 Likes
19
1 Like
20

This is what I came up with all your helphttps://beta.facer.io/watchface/AaLHhUu5ZH

6 Likes
21

Congratulations!!! It was beautiful!!!

1 Like
22

Nice watch - like your style. It gives me the impression I’m looking out of the ISS window

4 Likes
23

Good Work . Formula Stored in the Bits Box . :+1: :grin:

2 Likes
